AOHUA UHD-CL300Qi,UHD-CL300QL Video Colonoscope

Phone：+86-21-54286005

Resources

Overview Specifications Dimensions

AOHUA UHD-CL300Qi,UHD-CL300QL

Video Colonoscope

UHD-GT300Q

Dual Focus

With just one touch, you can swiftly switch between the standard focus mode and the near-focus mode, enhancing diagnostic and therapeutic efficiency on the foundation of precision care.

Dual Focus

CBI Mode

Through multispectral staining technology, blood vessels and tissues on the mucosal surface become more easily observable, aiding doctors in more precise and efficient disease diagnosis.

CBI Mode

3 Light Guides

The lens tip is equipped with a triple-window illumination system, delivering a more uniform and ample illumination effect. Combined with a wide field of view, it facilitates improved observation of the examination area.

3 Light Guides

Waterproof

The wireless power connection between the light source and endoscope is achieved through a contactless, wireless power supply method. One-touch insertion and removal reduce the cumbersome steps of detaching the endoscope, allowing for complete immersion without the need for additional waterproof covers, thus facilitating more convenient cleaning and disinfection.

Waterproof

Brand New Handle

More comfortable grip based on ergonomics and clinical feedback Lightweight non-slip material makes long hand-holding easier, less effort and more stable

Brand New Handle

Sync Force Transmission

Effectively transmits the Push-pull forces and rotational forces to the apex of the colonoscope Facilitate easier access to the cecum

Sync Force Transmission

Adjustable Stiffness

The softness of the Colonoscope can be adjusted using the adjustment ring Cater to the needs of different parts of the colon segments

Adjustable Stiffness

Elastic Bending

Adaptive twisting of the endoscope in response to the steering of different parts of the colon Effectively reducing the need for endoscope manipulation and improving patient comfort

Elastic Bending

Model		UHD-CL300Qi	UHD-CL300QL
Optical System	Field of view	Normal 170º Near 160º
	Depth of field	Normal 9-100 mm Near 1.5-9 mm
Insertion Section	Distal end outer diameter	12.2 mm
	Insertion tube outer diameter	12.0 mm
	Working length	1300 mm	1650 mm
Instrument Channel	Channel inner diameter	3.8 mm
Bending Section	Angulation range	Up 180º Down 180º Right 160º Left 160º
Total Length		1600 mm	1950 mm
